El Pixel LED es un módulo individual que posee un LED de 8mm junto con un micro integrado en cada uno de los módulos. La alimentación de los mismos es de 5V y debe utilizarse una fuente de 5V por cada 50 unidades.
Dimensiones
N/D
color
RGB
Código Producto
DE-PIX-12-RGB
Construcción
Aluminio/PC
Número y Tipo de LEDs
Epistar Led
Angulo De Apertura (º)
120
Información Adicional
Controlador y controlador necesarios en la pestaña "accesorios"
Temperatura Luz
RGB
Instalación
IP68
Tensión
5VDC
Vida Estimada (H)
40000
Medidas (mm)
12
Certificados
CE/ROHS/ISO9001
Dimable
Sí
Frecuencia de Trabajo (Hz)
50/ 60
Tiempo de Arranque (s)
0.1
Rango Temperatura (ºC)
-20 +60
Casquillo
Borna
Ciclos de Encendidos
80000
Difusor
Opal
Consumo de Energía (kWh/1000h)
0.3
CCT Único/Rango
Único
Normas Aplicables
EN 55015:2006; EN 61000-3-2:2006; EN 61547:2009; EN 61000-4-2:2009; EN 61000-4-3:2006; EN 61000-4-4:2004; EN 61000-4-6:2009; EN 61000-4-8:2010; EN 61000-4-11:2004
